Waterbox Aquariums

AIO 50.3

Sale price$1,735.50 AUD

• Dimensions (LxWxH): 900 x 500 x 450mm (35.4" x 19.7" x 17.7")
• Height with Cabinet:1350mm / 53.1"
• Display Volume: 186L / 49.1gal
• Glass Thickness: 10mm
• Includes: Aquarium Filter Sock, Carbon, Bio Balls (Pump sold separately, Cabinet Optional)
View Full Specifications

Color:White

The Display & Filtration

Newbie or Pro

The AIO was designed so you can keep more in your aquarium with less. Available from 20 through 65 gallons, the AIO delivers an aquatic environment for novice and professional aquarium keepers.

Adjustable Nozzle return allow for precise water agitation.
Ideal for novice and professional aquarium keepers
The unique filtration and baffle system forces the water to travel through the filter socks and then flow into chambers adequately sized for multiple types of filtration media.
AIO 20 & 25 include a perfectly matched return pump for optimal water turnover.
Filtration media is included to keep your water clear and polished.

The Cabinetry

Strength & Stability

Waterbox furniture is designed to elevate your living spaces with our first in class cabinetry and finishes. Available in white, black, or aspen.

Engineered to stand the test of time.
Constructed with aluminum framing to easily withstand the weight and humidity of your aquarium system.
Excluding AIO 20 Cube
Laminated wood panels skirt the aluminum framing for a sleek, modern look.
Adjustable Leveling Feet provide easy and effective way to ensure your aquarium is level, front to back and side-to-side.

Technical Specifications

Product Model AIO 10 CUBE AIO 15 Peninsula AIO 20 CUBE AIO 25 Peninsula
Aquarium Dimensions
(Length x Width x Height)
350 x 361 x 350mm 500 x 350 x 350mm 450 x 450 x 400mm 600 x 400 x 400mm
13.8"×14.2"×13.8" 19.7"×13.8"×13.8" 17.7"×17.7"×15.7" 23.6"×15.7"×15.7"
Glass Thickness 5mm (3/16") 5mm (3/16") 6mm (1/4") 6mm (1/4")
Water Height 335mm/13.2" 335mm/13.2" 385mm/15.2" 385mm/15.2"
Aquarium Volume 41 L/10.9 gals 57 L/15.2 gals 76 L/20.0 gals 90 L/23.7 gals
Aquairum Weight 11.5 kg / 25.4 lb 14.0 kg / 30.9 lb 19.5 kg / 43.0 lb 21.5 kg / 47.4 lb
Glass Material Ultra-clear glass
Transmittance 91%
Media/Skimmer Chamber 125 x 80 x 350mm 125 x 80 x 345mm 200 x 80 x 400mm 173 x 80 x 394mm
4.9"×3.1"×13.8" 4.9"×3.1"×13.5" 7.9"×3.1"×15.7" 6.8"×3.1"×15.5"
Filter Sock Chamber 80 x 80 x 350mm 80 x 80 x 350mm 80 x 80 x 400mm 80 x 80 x 400mm
3.1"×3.1"×13.8" 3.1"×3.1"×13.8" 3.1"×3.1"×15.7" 3.1"×3.1"×15.7"
Pump Chamber 80 x 95 x 350mm 80 x 95 x 350mm 80 x 118 x 400mm 80 x 118 x 400mm
3.1"×3.7"×13.8" 3.1"×3.7"×13.8" 3.1"×4.6"×15.7" 3.1"×4.6"×15.7"
Directional Nozzle 1 1 1 1
Return Hose Φ16 Φ16 Φ16 Φ16
EVA Mat 1 1 1 1
Accessories Pump Flow 600L/h 1000L/h 1000L/h 1000L/h
Directional Nozzle
Return Hose Φ16 Φ16 Φ16 Φ16
225 Micron FELT Socks 2.75“ x 1 x 1 x 1 x 1
Filtration Sponge x 2 x 2 x 2 x 2
Carbon Pellets
Ceramic Rings
EVA Mat
Mesh Lid
(Optional)
Mesh Lid
Cabinet
(Optional)
Cabinet Model - - PB1818 -
Dimensions - - 450 x 450 x 810mm -
- - 17.7"×17.7"×31.9" -
Material - - 18mm Particle Board, PVC Laminated -
Color - - WHT-White, BLK-Black, ASP-Aspen -
Product Model AIO 35.2 AIO 50.3 AIO 65.4
Aquarium Dimensions
(Length x Width x Height)
600 x 500 x 450mm 900 x 500 x 450mm 1200 x 500 x 450mm
23.6"×19.7"×17.7" 35.4"×19.7"×17.7" 47.2"×19.7"×17.7"
Glass Thickness 8mm (5/16") 10mm (2/5") 10mm (2/5")
Water Height 435mm/17.1" 435mm/17.1" 435mm/17.1"
Aquarium Volume 125 L/33 gals 186 L/49.1 gals 249 L/65.8 gals
Aquarium Weight 34.0 kg / 75.0 lb 59.0 kg / 130.1 lb 65.0 kg / 143.3 lb
Glass Material Ultra-clear glass
Transmittance 91%
Filtration Chamber 600 x 120 x 450mm 900 x 120 x 450mm 1200 x 120 x 450mm
23.6"×4.7"×17.7" 35.4"×4.7"×17.7" 47.2"×4.7"×17.7"
Filter Sock Chamber 81 x 120 x 450mm 81 x 120 x 450mm

161x120x450mm

3.2"×4.7"×17.7" 3.2"×4.7"×17.7" 6.3"×4.7"×17.7"
Filter Media/Skimmer Chamber 101 x 120 x 450mm 154 x 120 x 450mm

150 x 120 x 450mm

4"×4.7"×17.7" 6.1"×4.7"×17.7" 5.9"×4.7"×17.7"
Pump Chamber 140 x 120 x 450mm 300 x 120 x 450mm 221 x 120 x 450mm
5.5"×4.7"×17.7" 11.8"×4.7"×17.7" 8.7"×4.7"×17.7"
Directional Nozzle 1 2 2
Return Hose Φ16 Φ24 Φ24
EVA Mat 1 1 1
Filtration Filter Socks 70mm/2.75" x 2 70mm/2.75" x 2 70mm/2.75" x 4
Filtration Sponge 2 2 2
Bio ball 24 pcs 24 pcs 48 pcs
Cabinet Cabinet Model ALU 2420 ALU 3620 ALU 4820
Cabinet Dimensions 600 x 500 x 900mm 900 x 500 x 900mm 1,200 x 500 x 900mm
23.6" × 19.7" × 35.4" 35.4" × 19.7" × 35.4" 47.2" × 19.7" × 35.4"
Cabinet Framework Anti-corrosion Aluminum Alloy
Door & Side Panels 18mm PVC Laminated Wood Particle Board
Bottom Panels 10mm PVC Board
Back Panels 6mm PVC Board
Cabinet Color WHT-White, BLK-Black, ASP-Aspen
SUS304 Hinges
Leveling Feet
